Ctrl Command set_sky_writing_mode
Function switches Sky Writing mode on or off.
Call
set_sky_writing_mode( Mode )
Parameters Mode Desired Sky Writing mode as an unsigned 32-bit value
(allowed range: [0 … (2
32
–1)]):
= 0: Sky Writing (mode 1 or possibly mode 2 or 3) will be activated
= 1: Sky Writing mode 1 will be activated
= 2: Sky Writing mode 2 will be activated
> 2: Sky Writing mode 3 will be activated
Comments • You can only activate Sky Writing mode 2 and 3 (via
Mode > 1) if you had previously
(recently) called set_sky_writing_para with
Timelag  1/64 at least once (thus acti-
vating Sky Writing mode 1).
•After set_sky_writing_mode(
Mode = 0), subsequent Sky Writing reactivation is possible
via set_sky_writing_mode(
Mode > 0), but not after set_sky_writing_para with
Timelag < 1/64 (reactivation here would require a renewed call of
set_sky_writing_para with
Timelag  1/64).
• Each mode switch via set_sky_writing_mode becomes effective as of the next list
command.
• If you reactivate Sky Writing mode 1 (switching from
Mode = 0 to 1) during execution
of a list, then an already-begun mark or arc command will still execute to completion
without Sky Writing.
• If you deactivate Sky Writing mode 1 (switching from
Mode = 1 to 0) while a list is
executing, then a mark or arc command already begun in Sky Writing mode 1 will still
execute to completion in Sky Writing mode 1 and then be appended with a mark delay.
• Activation or deactivation of Sky Writing mode 2 or 3 (switching to or from
Mode = 2
or 3) isn’t possible if the board’s BUSY status is currently set (list is being processed or
has been halted via pause_list). Then the command will be ignored (get_last_error
return code:
RTC5_BUSY ). In contrast, the command is always executed when a list has
been paused via set_wait.
RTC
®
4  RTC
®
5 new command
Version info • Available beginning with version DLL 527, OUT 529, RBF 519
• Last change with version DLL 531, OUT 532: mode 3
References set_sky_writing_mode_list, set_sky_writing_para
