RTC

5 PC Interface Board

Rev. 1.9 e

10 Commands And Functions

504

innovators for industry

Undelayed

Short List

Command

set_wobbel_direction

Function defines a direction vector for wobbel motions.

Call

set_wobbel_direction( dX, dY )

Parameter

Components of the direction vector in bits as signed 32-bit values

Comments • For non-zero direction vectors (

and/or

non-zero), wobbel motion (longitudinal

and transversal) is relative to this direction vector instead of to the momentary direction

vector. The direction vector’s length is inconsequential. The RTC

5 normalizes the direc-

tion vector.

•If

= 0, then the function will be deactivated.

• The direction vector setting remains in effect even after the wobbel mode is switched

off via set_wobbel or set_wobbel_mode, and will continue being used if you switch

the wobbel mode back on.

RTC



RTC

5 new command

Version info Available as of version DLL 537, OUT 537

References set_wobbel, set_wobbel_direction, set_wobbel_mode
