Ctrl Command select_serial_set
Function selects a serial-number-set for serial number control commands.
Call
select_serial_set( No )
Parameter
No Number of the desired serial-number-set as an unsigned 32-bit value;
allowed range: [0 … 3]; only the two least significant bits are evaluated.
Comments • After initialization with load_program_file, serial-number-set 0 is selected.
• select_serial_set does not assign a serial-number-set for serial number marking. The list
command select_serial_set_list is intended for that purpose.
• For command usage, see chapter 7.5.2 "Marking Serial Numbers", page 150.
RTC
®
4  RTC
®
5 new command
Version info Available beginning with version DLL 537, OUT 537
References select_serial_set_list, set_serial_step, get_serial
Undelayed
Short
List Command
select_serial_set_list
Function selects a serial-number-set for serial number list commands (as well as for serial number
marking).
Call select_serial_set_list( No )
Parameter No Number of the desired serial-number-set as an unsigned 32-bit value; allowed
range: [0 … 3]; only the two least significant bits are evaluated.
Comments • After initialization with load_program_file, serial-number-set 0 is selected.
• For command usage, see chapter 7.5.2 "Marking Serial Numbers", page 150.
RTC
®
4  RTC
®
5 new command
Version info Available beginning with version DLL 537, OUT 537
References select_serial_set,set_serial_step_list, get_list_serial, mark_serial, mark_serial_abs
Ctrl Command send_user_data
Function sends data values via the user data bit to the specified scan system
Comments • Up to now, this command has no effect, but it is reserved for future use according to
chapter 7.3.6 "Status Monitoring and Diagnostics", page 127 and chapter 8.1.2
"Configuring Status Return Behavior", page 153.
References read_user_data
