Ctrl Command set_control_mode
Function enables or disables the external control input for external list starts, locks or unlocks the
external control input for external list stops and resets the counter for external list starts to
zero.
Call set_control_mode( Mode )
Parameter Mode (as an unsigned 32-bit value):
Bit # Value Description
Bit #0 (LSB) = 1: The external start input (via /START, /START2 or /Slave-START) is enabled.
= 0: The external start input is disabled.
Bit #1 = 1: An external list stop (/STOP, /STOP2, /Slave-STOP or simulate_ext_stop)
causes explicit cancellation of the external start queue’s entries (/START,
/START2, /Slave-START or simulate_ext_start).
= 0: no effect
Bit #2 = 1: The track delay (defined via simulate_ext_start, set_ext_start_delay or
set_ext_start_delay_list) that postpones execution of the list start relative to
the triggering input signal or simulate_ext_start or simulate_ext_start_ctrl
command (see "External List Start", page 210) is deactivated.
= 0: No effect. To define and activate the track delay (e.g. for Processing-on-the-fly
applications), use the command simulate_ext_start, set_ext_start_delay or
set_ext_start_delay_list.
Bit #3 = 1: The external start input is not disabled by an external stop request.
= 0: The external start input is disabled by an external stop request.
Bits #4-8 Reserved.
Bit #9 = 1: Encoder resets of the two internal encoder counters (initiated by the
Processing-on-the-fly commands set_fly_x, set_fly_y or set_fly_rot) occur
after the subsequent start trigger (i.e. the subsequent external start signal or
simulate_ext_start or simulate_ext_start_ctrl command, possibly
postponed by a track delay defined via simulate_ext_start,
set_ext_start_delay or set_ext_start_delay_list, also see bit #2).
= 0: Encoder resets occur immediately with each initiating Processing-on-the-fly
command.
Bits #10 = 1: Track delay configured via simulate_ext_start, set_ext_start_delay or
set_ext_start_delay_list will be counted beginning with the most recent
externally (but not with execute_list_pos etc.) triggered or simulated
external list start. The interval between subsequent external list starts (in
encoder pulses) will thus be constant (also see page 212). For
stop_execution or an external stop signal, bit #10 will get reset to “0”. This
bit has no effect if the firmware version is 506 or lower (see get_rtc_version).
= 0: Track delay configured via simulate_ext_start, set_ext_start_delay or
set_ext_start_delay_list will be counted beginning with the time point an
external list start was requested (i.e. with the corresponding
simulate_ext_start or simulate_ext_start_ctrl command or external start
signal). The interval between subsequent external list starts (in encoder
pulses) can thus vary. This is standard for firmware version 506 or lower (see
get_rtc_version).
Bits #12-15 reserved Version info
Comments • If execution is aborted by the command stop_execution, then bit #0 and bit #10 will
get reset to zero, thus deactivating external start inputs and the counting of track
delays with respect to a possible triggering event.
• If bit #9 = 0, then there will generally be a small (random) time offset (10 µs jitter)
between the start signal at /START, /START2 and the actual list start. If bit #9 = 1, then
this 10 µs jitter won’t be present because the encoder reset then occurs synchronously
with the start signal.
• Also see "External List Stop", page 209 and "External List Start", page 210.
