RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
471
innovators for industry
Normal
List Command
set_pulse_picking_list
Function same as set_pulse_picking (see above), but a list command
Call
set_pulse_picking_list( No )
Parameter No See set_pulse_picking.
RTC
®
4  RTC
®
5 new command
Version info Available beginning with version DLL 529, OUT 530, RBF 521
References set_pulse_picking
Ctrl Command set_qswitch_delay
Function In the YAG modes, defines the delay length of the first Q-Switch pulse with reference to
the FirstPulseKiller signal (also see figure 49 on page 134)
Call
set_qswitch_delay( Delay )
Parameter Delay Q-Switch Delay as an unsigned 32-bit value
1 bit equals 1/64 µs. Allowed range: [0…(2
26
–1)]
Comments • Values over (2
26
–1) will be clipped.
• The YAG modes are selectable via set_laser_mode ( [1, 2, 3 or 5] ).
• Also for YAG modes defined with set_laser_mode( [1-3] ), the length of the Q-Switch
delay can be subsequently changed via this command; and for YAG mode 2 also with
set_firstpulse_killer or set_firstpulse_killer_list.
RTC
®
4  RTC
®
5new command
In RTC
®
4 compatibility mode, the delay value must be specified in units of 1/8 µs. It will
then be internally converted to 1/64 µs units (i.e. multiplied by 8). The permissible range of
values is correspondingly smaller.
References set_qswitch_delay_list, set_laser_control, set_laser_pulses_ctrl, set_laser_pulses,
set_laser_timing, set_firstpulse_killer, set_firstpulse_killer_list
Undelayed
Short
List Command
set_qswitch_delay_list
Function same as set_qswitch_delay (see above), but a list command
Call
set_qswitch_delay_list( Delay )
Parameter Delay Q-Switch Delay as an unsigned 32-bit value
1 bit equals 1/64 µs. Allowed range: [0…(2
26
–1)]
RTC
®
4  RTC
®
5new command
References set_qswitch_delay
