List Command
micro_vector_abs
Function moves the output point (of the laser focus) via a hard jump (without microvectorization)
directly from the current position to the specified position (absolute coordinate values)
within a two-dimensional image field.
Call
micro_vector_abs( X, Y, LasOn, LasOff )
Parameters
X, Y
absolute coordinates of the micro vector end point in bits as signed 32-bit
values; allowed range: [–8388608 8388607] (out-of-range values will be
edge-clipped). The complete value range [–8388608 8388607] is only
usable as a virtual image field e.g. for (enabled) Processing-on-the-fly
applications. The current coordinates will be clipped to [–524288 524287]
(real image field size) during runtime directly prior to use of the correction
table.
LasOn,
LasOff
LaserOn delay and LaserOff delay as signed 32-bit values.
1bit equals 0.5µs.
Allowed range (as with set_laser_delays): [ 2
31
…+(2
15
1)]
0: Delay will be newly set (values over (2
15
–1) will be clipped).
< 0: The previously defined delay continues unaffected.
Comments For information on microvector command usage, also see page 197.
During the conversion of specified coordinate values into scan system output values,
any previously defined coordinate transformations, assigned correction tables etc. are
taken into account after successful microvectorization (see page 197).
The microvector always executes as a hard jump.
•Via
LasOn
0 and
LasOff
0, you can set a new LaserOn or LaserOff delay for each
individual microvector. Each delay will thereby get set at the end of the clock period in
which the new position actually gets outputted (this output clock cycle might be
delayed by a preceding scanner delay).
Negative values (
LasOn
<0 and
LasOff
< 0) don’t affect laser delays. Hereby, the laser
can remain on or off across multiple clock periods (mark and jump simulation).
Delays set with
LasOn
and
LasOff
only apply to the execution of microvectors. For
execution of normal mark and arc commands (such as mark_abs), only the laser delays
defined via set_laser_delays apply.
LasOn
and
LasOff
do not overwrite the laser delay
parameter from set_laser_delays.
The optional XY2-100 converter (see page 42) introduces a 10 µs runtime latency to
scan-system control. This runtime latency can be compensated by increasing the
LaserOn delay and LaserOff delay by 10 µs each.
RTC
®
4
RTC
®
5 new command
In RTC
®
4 compatibility mode, the RTC
®
5 multiplies the specified coordinate values by 16
and the specified delay values by 2. The permissible ranges of values are correspondingly
reduced.
Version info Last change with version DLL 536, OUT 536:
LasOn, LasOff <
2
15
References micro_vector_rel, micro_vector_abs_3d
