RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
385
innovators for industry
Ctrl Command read_analog_in
Function reads the analog input values (ANALOG IN0 and ANALOG IN1) from the
(RTC
®
5 PC interface board’s) optional ADC add-on board or from the RTC
®
5-Express
board’s “SPI / I2C” connector and returns them as 12-bit digital values.
Call
AnalogValue = read_analog_in()
Result an unsigned 32-bit value:
Bits#0…11 ANALOG IN0 input value as 12-bit digital value
Bit#12 = 0 (channel number)
Bits#13…14 = 0
Bit#15 Old bit for ANALOG IN0
Bits#16…27 ANALOG IN1 input value as 12-bit digital value
Bit#28 = 1 (channel number)
Bits#29…30 = 0
Bit#31 Old bit for ANALOG IN1
Comments This command can only be used together with an RTC
®
5-Express board or with an
RTC
®
5 PC interface board with installed ADC add-on board (see page 54 and
page 595), i.e. not together with an RTC
®
5 PC/104-Plus board or an RTC
®
5 PCIe/104
board.
The old bits (bits #15 and #31) are set to 1 after reading via read_analog_in. They will
be automatically reset, when new data are available at the corresponding analog input.
RTC
®
4
RTC
®
5 new command
Version info Available beginning with version DLL 527, OUT 529, RBF 519
Ctrl Command read_encoder
Function returns the counts of the two RTC
®
5 encoder counters that were stored via
store_encoder.
Call
read_encoder( &Encoder0_0, &Encoder1_0, &Encoder0_1, &Encoder1_1 )
Returned para-
meter values
Encoder0_0,
Encoder1_0,
Encoder0_1,
Encoder1_1
counts as pointers to signed 32-bit values.
For parameter “Encodern_m”,
n is the number of the encoder counter (Encoder0, Encoder1)
m is the number of the buffer position (parameter
Pos
of
store_encoder)
Comments Also see "Processing-on-the-fly (Optional)", page 177 and "Synchronization via Encoder
Signals", page 215.
If incremental encoders are used to detect the motion of the parts to be processed,
encoder counter Encoder0 will be triggered by the signals at encoder input ENCODER X
and encoder counter Encoder1 by the signals at encoder input ENCODER Y. In contrast,
if an encoder simulation has been started via simulate_encoder, both encoder
counters will be triggered by an internal periodic 1 MHz clock signal.
For buffer positions in which counts were not previously stored via store_encoder, the
value 0 will be returned (initialized value).
RTC
®
4
RTC
®
5 new command
Version info Available beginning with version DLL 520, OUT 519
References store_encoder, get_encoder, set_fly_x, set_fly_y, set_fly_rot, wait_for_encoder
