RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
384
Comments • No monitoring takes place if the specified scan head does not have a correction table
assigned (see select_cor_table).
• The used position limits (that is, if exceeded the emergency action is executed) are the
parameters of a customer-specific Processing-on-the-fly application monitoring (see
set_fly_limits, set_fly_limits_z). Exceeding these limits only cause error messages in
case of Processing-on-the-fly applications. The error messages can be queried with
get_marking_info or the respective
if_fly_<axis>_overflow/if_not_fly_<axis>_overflow commands. They do not trigger
any activities.
• Processing-on-the-fly applications use the data type
Data
= 0 (sample values) for
customer-specific range limits. Inconsistent error messages and switch-offs may occur
if used simultaneously with range_checking data types
Data
> 0.
•The range_checking monitoring is active without Processing-on-the-fly application.
•
Data
> 5 causes a get_last_error
RTC5_PARAM_ERROR
error code. In this case the
command is sent to the RTC
®
5 board as list_nop.
•
Data
=2 and
Data
=3 have the identical effect for the Z axis.
•For
Data
= 4 and
Data
= 5 the user must define the set position as the to be returned
data type. A simultaneous use of a speed-dependent laser control with
Mode
= 2 (see
set_auto_laser_control) is not possible.
•
Data
= 4 and
Data
= 5 only differ in regards to the axis onto an optional varioSCAN is
connected. For 2D systems without varioSCAN both selections have the identical effect.
•
Data
= 4 und
Data
= 5 may produce nonsensical switch-offs if an intelliSCAN
®
is
connected but is either not switched-on or a real position has not been set as feedback.
• If the laser has been switched-off with
Mode
= 0 and the fault condition is gone then
the laser is not switched on until the next marking command. The laser is not switched-
on right in the middle of a currently executing marking command.
RTC
®
4
RTC
®
5new command
Version info Available beginning with version DLL 537, OUT 537
References set_fly_limits, set_fly_limits_z
Undelayed
Short List
Command
range_checking
