RTC
®
5 PC Interface Board
Rev. 1.9 e
16 Appendix B: The RTC
®
5-Express Board
596
innovators for industry
16.3 Installation and Start-Up
For installing and starting-up an RTC
®
5-Express
board and its software proceed as with an
RTC
®
5 PC interface board (see page 56).
16.4 Technical Specifications of
RTC
®
5 PC/104-Plus Board
Caution!
•The RTC
®
5-Express board does not support
power-saving modes that switch off power to
the PCI-Express bus. Accordingly, you must
disable standby or sleep modes of the operating
system. Particularly disable the WINDOWS sleep
mode option (some WINDOWS operating
systems enable this option by default). Also see
the note on page 27.
System Requirements
IBM-compatible PC with PCI-Express bus interface
Operating system Microsoft (32 bit or 64 bit)
WINDOWS 8,
WINDOWS 7,
WINDOWS Vista and
WINDOWS XP (SP2 or
higher)
Dimensions
Length 160 mm
Height 104.5 mm
Interface to Scan System
PCI-Express x 1, version 1.0
“SPI / I2C” Connector
Connector 10-pin socket connector
McBSP interface identical to
RTC
®
5PCinterface board
(see page 52)
2 Analog inputs (ANALOG IN0, ANALOG IN1):
• Input voltage range
• Input resistance
• ADC resolution
• Reference
0V…10V
4k
12 bit
GND
Other Connectors and Specifications
Identical to RTC
®
5 PC interface board
