Scanlab RTC 5 PC Interface Board - set_sky_writing_para

RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
481
innovators for industry
Ctrl Command set_sky_writing_para
Function activates or deactivates Sky Writing mode and sets the corresponding parameters
Call
set_sky_writing_para( Timelag, LaserOnShift, Nprev, Npost )
Parameters Timelag Sky Writing parameter as a 64-bit IEEE floating point value
1.0 equals 1 µs.
Up to DLL 536, the following applies:
 1/4: Sky Writing mode 1 will be activated
< 1/8: Sky-Writing (mode 1 or mode 2 or 3 when applicable) will be
deactivated
As of DLL 537, the following applies:
 1/4: Sky-Writing mode 1 will be activated. From 1/8 to 1/4, Sky-Writing
will be activated, but
Timelag = 0 will be internally applied.
< 1/8: Sky-Writing (mode 1 or mode 2 or 3 when applicable) will be
deactivated
LaserOnShift Shift (for positive values: delay) of the point of time, where the laser
control signals are switched on as a signed 32-bit value (see figure 43 on
page 116). 1bit equals 0.5µs.
Negative values smaller than the complete run-in phase will be clipped,
therefore the following applies automatically
–
LaserOnShift  approx. (–40) · Nprev (mode 1)
–
LaserOnShift  approx. (–20) · Nprev (mode 2 or 3)
Nprev This parameter (an unsigned 32-bit value) defines the duration of the run-
in phase (see figure 43 on page 116). 1 bit equals 10 µs.
run-in duration / µs = 20 ·
Nprev (mode 1)
run-in duration / µs = 10 · Nprev (mode 2 or 3)
Allowed range: 0 
Nprev  (2
32
–1)
Npost This parameter (an unsigned 32-bit value) defines the duration of the run-
out phase (see figure 43 on page 116). 1bit equals 10µs.
run-out duration / µs = 20 ·
Npost (mode 1)
run-out duration / µs = 10 ·
Npost (mode 2 or 3)
Allowed range: 0 
Npost  (2
32
–1)
