Comments • For information on Sky Writing mode and a description of the parameters, see "Sky
Writing", page 113.
•If
Nprev  65535, then set_sky_writing_para behaves similarly to set_sky_writing:
Nprev is set to a value of approx. (0.15 · Timelag ), i.e.
– run-in duration / µs = approx. 3 ·
Timelag (mode 1)
– run-in duration / µs = approx. 1.5 ·
Timelag (mode 2 or 3)
Here, Nprev gets clipped to the maximum value of 65535 if necessary.
•If
Npost  65535, then set_sky_writing_para behaves similarly to set_sky_writing:
Npost is set to a value of approx. (0.1 · Timelag ), i.e.
– run-out duration / µs = approx. 2 ·
Timelag (mode 1)
– run-out duration / µs = approx. 1 ·
Timelag (mode 2 or 3)
Here,
Npost gets clipped to the maximum value of 65535 if necessary.
• set_sky_writing_para cannot be used to switch back and forth between Sky Writing
modes 1, 2 and 3 (the proper command for this is set_sky_writing_mode).
• If you call set_sky_writing_para (
Timelag  1/64) while Sky Writing is deactivated,
then Sky Writing mode 1 will get activated. If the command call succeeds during execu-
tion of a list, then mode 1 will only become active as of the next list command (an
already-begun mark or arc command will still execute to completion without Sky
Writing).
• If you call set_sky_writing_para while Sky Writing mode 1 is activated, then the
supplied parameters become active as of the next list command. If the command call
succeeds during execution of a list, then:
–If (
Timelag  1/64), then Sky Writing for an already begun mark or arc command will
execute to completion still using the existing parameters
–If (
Timelag < 1/64), then a mark or arc command already begun in Sky Writing
mode 1 will still complete in Sky Writing mode 1 and then be appended with a mark
delay.
• When you call set_sky_writing_para while both Sky Writing mode 2 or 3 is activated
and the board’s BUSY status is currently set (list is being processed or has been halted
via pause_list), then the command will be ignored (get_last_error return code:
RTC5_BUSY ). In contrast, the command executes when no list is currently running or
when a list has been paused via set_wait.
–If
Timelag < 1/64, then Sky Writing mode 2 or 3 will be deactivated.
–If
Timelag  1/64, then the supplied parameters become effective as of the next list
command. For Sky Writing mode 2 or 3, however,
Nprev = 0 and/or Npost =0 will
automatically get internally corrected to 1 (this is not treated as an error). If you sub-
sequently activate Sky Writing mode 1 (via set_sky_writing_mode), then
Nprev =0
and/or
Npost = 0 will be reused.
RTC
®
4  RTC
®
5 new command
Version info Last change with version DLL 537, OUT 537:
Timelag
References set_sky_writing, set_sky_writing_para_list
Ctrl Command set_sky_writing_para
