Scanlab RTC 5 PC Interface Board - set_sky_writing_para_list

RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
483
innovators for industry
Normal
List Command
set_sky_writing_para_list
Function identical with set_sky_writing_para (see above), but a list command
Call
set_sky_writing( Timelag, LaserOnShift, Nprev, Npost )
Parameters Timelag See set_sky_writing_para.
LaserOnShift See set_sky_writing_para.
Nprev See set_sky_writing_para.
Npost See set_sky_writing_para.
Comments • Unlike set_sky_writing_para, the command set_sky_writing_para_list is also execut-
able within a list if Sky Writing mode 2 or 3 is active. Here, Sky Writing temporarily
switches from mode 2 or 3 to mode 1: if necessary, the immediately preceding marking
command completes in mode 1 and the next marking command, too, begins in
mode 1. Afterward, mode 2 or 3 gets reactivated if
Timelag  1/64. The following also
applies:
–If
Timelag  1/64, then the supplied parameters become effective as of the next list
command (
Nprev = 0 and/or Npost = 0: see set_sky_writing_para).
–If
Timelag < 1/64, then Sky Writing is permanently deactivated.
• As with set_sky_writing_para, you can’t use set_sky_writing_para_list to perma-
nently switch from Sky Writing mode 2 or 3 to Sky Writing mode 1.
• Deactivation of Sky Writing mode 1, 2 or 3 via set_sky_writing_para_list results in the
addition of a mark delay defined prior to activation of Sky Writing – provided that no
other delay is in effect (e.g. a jump delay).
RTC
®
4  RTC
®
5 new command
Version info Last change with version DLL 531, OUT 532: mode 3
References set_sky_writing_para
