Scanlab RTC 5 PC Interface Board - set_char_table

RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
411
innovators for industry
Ctrl Command set_char_table
Function stores the absolute start address of a command list in the internal management table for
indexed text strings.
Call
set_char_table( Index, Pos )
Parameters Index Index of the indexed text string whose starting address Pos should be entered
in the management table (as an unsigned 32-bit value, allowed range:
[0 … 41]). The same ordering applies as for the load_text_table command:
= 0… 9: digits for marking the time and date [0 … 9]
= 10…21: months [January … December]
= 22…28: days-of-the-week [Sunday … Saturday]
= 29: blank character for marking serial numbers
= 30…39: digits for marking serial numbers [0 … 9]
= 40: text for “a.m.”
= 41: text for “p.m.”
Pos Absolute start address as an unsigned 32-bit value;
allowed range: [0 … (2
20
–1)]
Comments • The command is synonymous with set_text_table_pointer.
RTC
®
4  RTC
®
5 unchanged functionality (except for the extended range of values)
(the command was previously only available for the RTC
®
SCANalone Board, i.e. the
standalone version of the RTC
®
4 board)
References set_text_table_pointer
