RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
383
innovators for industry
Call
range_checking ( HeadNo, Mode, Data )
Parameter
HeadNo
scan head to be monitored as an unsigned 32-bit value.
0: No monitoring
(default after load_program_file).
1: Primary scan head is monitored.
2: Secondary scan head is monitored.
3: Both scan heads are monitored.
Only the 2 least significant bits are evaluated.
Mode
action to take as an unsigned 32-bit value.
0: Laser is switched-off immediately and list execution
continues.
1: Laser is switched-off immediately and list execution
is stopped immediately (as with stop_execution or
/STOP
).
Data
data type chosen to be monitored as an unsigned 32-bit value.
0: Sample values (Processing-on-the-fly and Wobbel corrected,
as with set_trigger signal types 7–9).
1: Transformed control values (with scan head-specific
transformations, as with set_trigger signal types 25–30).
2: Corrected control values (with correction file,
as with set_trigger signal types 10–15).
3: Actual output values (with “Offset” and “Gain”,
as with set_trigger signal types 20–23).
4: Real position of galvanometer (only with iDRIVE
®
systems,
varioSCAN is internally connected to an X axis,
as with set_trigger signal types 1, 2 and 3).
5: Real position of galvanometer (only with iDRIVE
®
systems,
varioSCAN is internally connected to an Y axis,
as with set_trigger signal types 1, 2 and 4)
Undelayed
Short List
Command
range_checking
