RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
251
innovators for industry
Comments General comments:
•The control_command command can only be used in conjunction with an iDRIVE
®
scan
system (intelliSCAN
®
, intelliSCAN
de
®
, intelliDRILL
®
, intellicube
®
, intelliWELD
®
, varioSCAN
de
)
with XY2-100 interface and XY2-100 converter. Conventional scan systems (without iDRIVE
®
technology) will ignore the command.
With invalid values of
Head
and/or
Axis
, the command is not executed (get_last_error return
code:
RTC5_PARAM_ERROR
). This also applies for
Head
= 2 if the “second scan head control”
option has not been enabled.
Command code
Data
is transmitted to the scan system instead of the usual position data for
Head
and
Axis
. Therefore, the corresponding galvanometer scanner microstep is omitted, if the
command is called during execution of a list.
Some parameters of control_command are not usable with older firmware versions of “intelli”
scan systems. These parameters are specifically noted. All other parameters are usable with any
firmware version.
Under some circumstances, control_command might be unavailable at the primary scan head
connector if speed-dependent laser control has been activated via set_auto_laser_control
(
Mode
=2).
Comments regarding the commands SetMode (Code
H
= 05
H
), SetControlDefinitionMode
(Code
H
=0E
H
), SetEchoMode (Code
H
= 21
H
) and RestoreTransmissionMode (
Data
= 1700
H
):
The data type selected via the control_command command (Code
H
= 05
H
, 0E
H
or 21
H
or
Data
= 1700
H
) will be transmitted until another data type is selected.
Data returned to the RTC
®
5 can be queried via the commands get_value, get_values,
set_trigger/set_trigger4 and get_waveform. Switching to a different data source causes a
short (serial transmission-related) delay before transmission of the first data. After switching
data sources, therefore, a delay time of up to 60 µs can occur before reading the data. As of
DLL version 520, control_command always automatically inserts a waiting time of 60 µs after
the data source is switched (so that the previously mentioned commands will now always
return correct values).
All data returned from the scan system are transmitted to the RTC
®
5 as signed 20-bit values.
This applies even if the DLL is set to RTC
®
4 compatibility mode and even for scan systems
without SL2-100 interface, controlled via an XY2-100 converter. Queried data returned via the
commands get_value, get_values or get_waveform are nevertheless generally transferred to
the PC as 32-bit signed values (for data evaluation, see comments for get_value).
For scan systems with integrated SL2-100 interface, get_head_status queries the XY2-100
status word regardless of settings made via control_command (Code
H
= 05
H
, 0E
H
or 21
H
or
Data
= 1700
H
). It will be returned in addition to the selected data. In contrast, if iDRIVE
®
scan
systems (without an integrated SL2-100 interface) are controlled via an XY2-100 converter,
get_head_status will return the XY2-100 status word only if this signal was previously selected
to be returned from the scan system via control_command (also see page 153).
After a reset or power-up of the scan system, it can take around 5 seconds for data to be
returned from the scan system (also see get_value). After a reset or power-up of the scan
system, always the XY2-100 status word is returned.
control_command (
Data
= 1700
H
) has no effect if a power-up or reset was executed after the
most recent execution of the StoreTransmissionMode command (
Data
= 17FF
H
).
Ctrl Command control_command
