Date _______________
Group______________
SET.3
of 66
SEL-787 Settings Sheets
Group Settings (SET Command)
Date Code 20150130 Instruction Manual SEL-787 Relay
PHASE IOC DELAY (0.00–5.00 sec)
(Hidden if 50P13P := OFF)
50P13D :=
PH IOC TRQCTRL (SEL
OGIC) (Hidden if 50P13P := OFF) 50P13TC :=
PHASE IOC LEVEL (OFF, 0.50–96.00 A [5 A nom.],
0.10–19.20 A [1 A nom.])
50P14P :=
PHASE IOC DELAY (0.00–5.00 sec)
(Hidden if 50P14P := OFF) 50P14D :=
PH IOC TRQCTRL (SEL
OGIC) (Hidden if 50P14P := OFF) 50P14TC :=
Winding 1 Residual Overcurrent
(All settings below are hidden when W1CT := DELTA.)
RES IOC LEVEL (OFF, 0.50–96.00 A [5 A nom.],
0.10–19.20 A [1 A nom.])
50G11P :=
RES IOC DELAY (0.00–5.00 sec)
(Hidden if 50G11P := OFF) 50G11D :=
RES IOC TRQCTRL (SEL
OGIC) (Hidden if 50G11P := OFF) 50G11TC :=
RES IOC LEVEL (OFF, 0.50–96.00 A [5 A nom.],
0.10–19.20 A [1 A nom.])
50G12P :=
RES IOC DELAY (0.00–5.00 sec)
(Hidden if 50G12P := OFF) 50G12D :=
RES IOC TRQCTRL (SEL
OGIC) (Hidden if 50G12P := OFF) 50G12TC :=
Winding 1 Negative-Sequence Overcurrent
NSEQ IOC LEVEL (OFF, 0.50–96.00 A [5 A nom.],
0.10–19.20 A [1 A nom.])
50Q11P :=
NSEQ IOC DELAY (0.00–5.00 sec)
(Hidden if 50Q11P := OFF)
50Q11D :=
NSEQ IOC TRQCTRL (SEL
OGIC)
(Hidden if 50Q11P := OFF)
50Q11TC :=
NSEQ IOC LEVEL (OFF, 0.50–96.00 A [5 A nom.],
0.10–19.20 A [1 A nom.])
50Q12P :=
NSEQ IOC DELAY (0.00–5.00 sec)
(Hidden if 50Q12P := OFF)
50Q12D :=
NSEQ IOC TRQCTRL (SEL
OGIC)
(Hidden if 50Q12P := OFF)
50Q12TC :=
Winding 1 Maximum Phase Time Overcurrent
PHASE TOC LEVEL (OFF, 0.50–16.00 A [5 A nom.],
0.10–3.20 A [1 A nom.])
51P1P :=
PHASE TOC CURVE (U1, U2, U3, U4, U5, C1, C2, C3, C4,
C5)
(Hidden if 51P1P := OFF)
51P1C :=
PHASE TOC TDIAL (0.50–15.00 for U1–U5 OR
0.05–1.00 for C1–C5)
(Hidden if 51P1P := OFF)
51P1TD :=
EM RESET DELAY (Y, N)
(Hidden if 51P1P := OFF) 51P1RS :=
CONST TIME ADDER (0.00–1.00 sec)
(Hidden if 51P1P := OFF)
51P1CT :=
MIN RESPONSE TIM (0.00–1.00 sec)
(Hidden if 51P1P := OFF)
51P1MR :=
PH TOC TRQCTRL (SEL
OGIC) (Hidden if 51P1P := OFF) 51P1TC :=
To Next Page
