SEL-787 Settings Sheets
Group Settings (SET Command)
Date _______________
Group______________
SEL-787 Relay Instruction Manual Date Code 20150130
Winding 1 Phase A Time Overcurrent
PHASE TOC LEVEL (OFF, 0.50–16.00 A [5 A nom.],
0.10–3.20 A [1 A nom.])
51P1AP :=
PHASE TOC CURVE (U1, U2, U3, U4, U5,
C1, C2, C3, C4, C5)
(Hidden if 51P1AP := OFF)
51P1AC :=
PHASE TOC TDIAL (0.50–15.00 for U1–U5 OR
0.05–1.00 for C1–C5)
(Hidden if 51P1AP := OFF)
51P1ATD :=
EM RESET DELAY (Y, N)
(Hidden if 51P1AP := OFF) 51P1ARS :=
CONST TIME ADDER (0.00–1.00 sec)
(Hidden if 51P1AP := OFF)
51P1ACT :=
MIN RESPONSE TIM (0.00–1.00 sec)
(Hidden if 51P1AP := OFF)
51P1AMR :=
PH TOC TRQCTRL (SEL
OGIC) (Hidden if 51P1AP := OFF) 51P1ATC :=
Winding 1 Phase B Time Overcurrent
PHASE TOC LEVEL (OFF, 0.50–16.00 A [5 A nom.],
0.10–3.20 A [1 A nom.])
51P1BP :=
PHASE TOC CURVE (U1, U2, U3, U4, U5, C1, C2, C3, C4,
C5)
(Hidden if 51P1BP := OFF)
51P1BC :=
PHASE TOC TDIAL (0.50–15.00 for U1–U5 OR
0.05–1.00 for C1–C5)
(Hidden if 51P1BP := OFF)
51P1BTD :=
EM RESET DELAY (Y, N)
(Hidden if 51P1BP := OFF) 51P1BRS :=
CONST TIME ADDER (0.00–1.00 sec)
(Hidden if 51P1BP := OFF)
51P1BCT :=
MIN RESPONSE TIM (0.00–1.00 sec)
(Hidden if 51P1BP := OFF)
51P1BMR :=
PH TOC TRQCTRL (SEL
OGIC) (Hidden if 51P1BP := OFF) 51P1BTC :=
Winding 1 Phase C Time Overcurrent
PHASE TOC LEVEL (OFF, 0.50–16.00 A [5 A nom.],
0.10–3.20 A [1 A nom.])
51P1CP :=
PHASE TOC CURVE (U1, U2, U3, U4, U5, C1, C2, C3, C4,
C5)
(Hidden if 51P1CP := OFF)
51P1CC :=
PHASE TOC TDIAL (0.50–15.00 for U1–U5 OR
0.05–1.00 for C1–C5)
(Hidden if 51P1CP := OFF)
51P1CTD :=
EM RESET DELAY (Y, N)
(Hidden if 51P1CP := OFF) 51P1CRS :=
CONST TIME ADDER (0.00–1.00 sec)
(Hidden if 51P1CP := OFF)
51P1CCT :=
MIN RESPONSE TIM (0.00–1.00 sec)
(Hidden if 51P1CP := OFF)
51P1CMR :=
PH TOC TRQCTRL (SEL
OGIC) (Hidden if 51P1CP := OFF) 51P1CTC :=
Winding 1 Residual Time Overcurrent
All settings below are hidden when W1CT := DELTA.
RES TOC LEVEL (OFF, 0.50–16.00 A [5 A nom.],
0.10–3.20 A [1 A nom.])
51G1P :=
