Sel SEL-787 - Page 231

Date _______________
Group______________
SET.9
of 66
SEL-787 Settings Sheets
Group Settings (SET Command)
Date Code 20150130 Instruction Manual SEL-787 Relay
RTD1 LOCATION (OFF, AMB, OTH) RTD1LOC :=
RTD1 IDENTIFIER (10 characters)
(Hidden if RTD1LOC := OFF or AMB)
RTD1NAM :=
RTD1 TYPE (PT100, NI100, NI120, CU10)
(All RTD settings below hidden if E49RTD := NONE)
RTD1TY :=
RTD1 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD1LOC := OFF)
TRTMP1 :=
RTD1 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD1LOC := OFF)
ALTMP1 :=
RTD2 LOCATION (OFF, AMB, OTH)
RTD2LOC :=
RTD2 IDENTIFIER (10 characters)
(Hidden if RTD2LOC := OFF or AMB)
RTD2NAM :=
RTD2 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD2LOC := OFF)
RTD2TY :=
RTD2 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD2LOC := OFF)
TRTMP2 :=
RTD2 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD2LOC := OFF)
ALTMP2 :=
RTD3 LOCATION (OFF, AMB, OTH)
RTD3LOC :=
RTD3 IDENTIFIER (10 characters)
(Hidden if RTD3LOC := OFF or AMB)
RTD3NAM :=
RTD3 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD3LOC := OFF)
RTD3TY :=
RTD3 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD3LOC := OFF)
TRTMP3 :=
RTD3 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD3LOC := OFF)
ALTMP3 :=
RTD4 LOCATION (OFF, AMB, OTH)
RTD4LOC :=
RTD4 IDENTIFIER (10 characters)
(Hidden if RTD4LOC := OFF or AMB)
RTD4NAM :=
RTD4 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD4LOC := OFF)
RTD4TY :=
RTD4 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD4LOC := OFF)
TRTMP4 :=
RTD4 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD4LOC := OFF)
ALTMP4 :=
RTD5 LOCATION (OFF, AMB, OTH)
RTD5LOC :=
RTD5 IDENTIFIER (10 characters)
(Hidden if RTD5LOC := OFF or AMB)
RTD5NAM :=
RTD5 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD5LOC := OFF)
RTD5TY :=
RTD5 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD5LOC := OFF)
TRTMP5 :=
RTD5 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD5LOC := OFF)
ALTMP5 :=
