SEL-787 Settings Sheets
Group Settings (SET Command)
Date _______________
Group______________
SEL-787 Relay Instruction Manual Date Code 20150130
RTD6 LOCATION (OFF, AMB, OTH) RTD6LOC :=
RTD6 IDENTIFIER (10 characters)
(Hidden if RTD6LOC := OFF or AMB)
RTD6NAM :=
RTD6 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD6LOC := OFF)
RTD6TY :=
RTD6 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD6LOC := OFF)
TRTMP6 :=
RTD6 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD6LOC := OFF)
ALTMP6 :=
RTD7 LOCATION (OFF, AMB, OTH)
RTD7LOC :=
RTD7 IDENTIFIER (10 characters)
(Hidden if RTD7LOC := OFF or AMB)
RTD7NAM :=
RTD7 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD7LOC := OFF)
RTD7TY :=
RTD7 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD7LOC := OFF)
TRTMP7 :=
RTD7 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD7LOC := OFF)
ALTMP7 :=
RTD8 LOCATION (OFF, AMB, OTH)
RTD8LOC :=
RTD8 IDENTIFIER (10 characters)
(Hidden if RTD8LOC := OFF or AMB)
RTD8NAM :=
RTD8 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD8LOC := OFF)
RTD8TY :=
RTD8 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD8LOC := OFF)
TRTMP8 :=
RTD8 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD8LOC := OFF)
ALTMP8 :=
RTD9 LOCATION (OFF, AMB, OTH)
RTD9LOC :=
RTD9 IDENTIFIER (10 characters)
(Hidden if RTD9LOC := OFF or AMB)
RTD9NAM :=
RTD9 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD9LOC := OFF)
RTD9TY :=
RTD9 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD9LOC := OFF)
TRTMP9 :=
RTD9 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD9LOC := OFF)
ALTMP9 :=
RTD10 LOCATION (OFF, AMB, OTH)
RTD10LOC:=
RTD10 IDENTIFIER (10 characters)
(Hidden if RTD10LOC := OFF or AMB)
RTD10NAM:=
RTD10 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD10LOC := OFF)
RTD10TY :=
RTD10 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD10LOC := OFF)
TRTMP10 :=
RTD10 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD10LOC := OFF)
ALTMP10 :=
