Sel SEL-787 - Page 251

Date _______________
Group______________
SET.29
of 66
SEL-787 Settings Sheets
Global Settings (SET G Command)
Date Code 20150130 Instruction Manual SEL-787 Relay
Phasor Measurement (PMU)
EN SYNCHRO PHSOR (Y, N) (All subsequent PMU settings
hidden if EPMU :=N)
EPMU :=
MESSAGES PER SEC (1, 2, 5, 10)
MRATE :=
STATION NAME (16 characters)
PMSTN :=
PMU HARDWARE ID (1–65534)
PMID :=
VOLTAGE DATA SET (V1, ALL, NA)
(Hidden if no voltages) PHDATAV :=
VOLT COMP ANGLE (-179.99 to 180.00 deg)
(Hidden if
PHDATAV := NA)
VCOMP :=
CURRENT DATA SET (I1, ALL, NA)
PHDATAI :=
CURRENT SOURCE (IW1, IW2, BOTH)
(Hidden if
PHDATAI := NA)
PHCURR :=
IW1 COMP ANGLE (-179.99 to 180.00 deg)
(Hidden if PHCURR := IW2 or if PHDATAI := NA)
IW1COMP :=
IW2 COMP ANGLE (-179.99 to 180.00 deg)
(Hidden if PHCURR := IW1 or if PHDATAI := NA)
IW2COMP :=
NUM ANALOGS (0–4)
NUMANA :=
NUM 16BIT DIGTAL (0, 1)
NUMDSW :=
TRIG REASON BIT1 (SEL
OGIC) TREA1 :=
TRIG REASON BIT2 (SEL
OGIC) TREA2 :=
TRIG REASON BIT3 (SEL
OGIC) TREA3 :=
TRIG REASON BIT4 (SEL
OGIC) TREA4 :=
TRIGGER ((SEL
OGIC) PMTRIG :=
Time and Date Management
CTRL BITS DEFN (NONE, C37.118) IRIGC :=
OFFSET FROM UTC (–24.00 to 24.00) rounded up to quarter
UTC_OFF :=
MONTH TO BEGIN DST (OFF, 1–12)
DST_BEGM :=
WEEK OF THE MONTH TO BEGIN DST (1–3, L) L = Last
week of the month (
Hidden if DST_BEGM := OFF)
DST_BEGW :=
DAY OF THE WEEK TO BEGIN DST (SUN, MON, TUE,
WED, THU, FRI, SAT) (
Hidden if DST_BEGM := OFF)
DST_BEGD :=
LOCAL HOUR TO BEGIN DST (0–23)(
Hidden if
DST_BEGM := OFF
)
DST_BEGH :=
MONTH TO END DST (1–12) (
Hidden if DST_BEGM := OFF) DST_ENDM :=
WEEK OF THE MONTH TO END DST (1–3, L) L = Last
week of the month (
Hidden if DST_BEGM := OFF)
DST_ENDW :=
DAY OF THE WEEK TO END DST (SUN, MON, TUE,
WED, THU, FRI, SAT) (
Hidden if DST_BEGM := OFF)
DST_ENDD :=
LOCAL HOUR TO END DST (0–23) (
Hidden if
DST_BEGM := OFF
)
DST_ENDH :=
Breaker Failure
52A INTERLOCK (Y, N) 52ABF :=
