SET.30
of 66
SEL-787 Settings Sheets
Global Settings (SET G Command)
Date _______________
Group______________
SEL-787 Relay Instruction Manual Date Code 20150130
BRKR1 FAIL DELAY (0.00–2.00 sec) BFD1 :=
BRKR1 FAIL INITIATE ((SEL
OGIC) BFI1 :=
BRKR2 FAIL DELAY (0.00–2.00 sec)
BFD2 :=
BRKR2 FAIL INITIATE ((SEL
OGIC) BFI2 :=
Through Fault
THR FLT WDG (OFF, 1, 2) THFLTD :=
ENABLE THR FLT ((SEL
OGIC)
(Hidden if THFLTD := OFF)
ETHRFLT :=
THR FLT ALARM PU (50.0–900.0 %)
(Hidden if THFLTD := OFF)
THFLTPU :=
XFMR IMPEDANCE (2.0–40.0 %)
(Hidden if THFLTD := OFF)
XFMRZ :=
Analog Inputs
For the following settings, x is the card position (3, 4, or 5 in Slot C, D, and E, respectively).
AIx01
AIx01 TAG NAME (8 characters 0–9, A–Z, _) AIx01NAM :=
AI
x01 TYPE (I, V) AIx01TYP :=
If AI
x01TYP = I
AI
x01 LOW IN VAL (–20.480 to +20.480; mA) AIx01L :=
AI
x01 HI IN VAL (–20.480 to +20.480; mA) AIx01H :=
If AI
x01TYP = V
AI
x01 LOW IN VAL (–10.240 to +10.240 V) AIx01L :=
AI
x01 HI IN VAL (–10.240 to +10.240 V) AIx01H :=
NOTE: Set Warn and Alarm to a value between Engr Low and
Engr High settings.
AI
x01 ENG UNITS (16 characters) AIx01EU :=
AI
x01 EU LOW (–99999.000 to +99999.000) AIx01EL :=
AI
x01 EU HI (–99999.000 to +99999.000) AIx01EH :=
AI
x01 LO WARN L1 (OFF, –99999.000 to +99999.000) AIx01LW1 :=
AI
x01 LO WARN L2 (OFF, –99999.000 to +99999.000) AIx01LW2 :=
AI
x01 LO ALARM (OFF, –99999.000 to +99999.000) AIx01LAL :=
AI
x01 HI WARN L1 (OFF, –99999.000 to +99999.000) AIx01HW1 :=
AI
x01 HI WARN L2 (OFF, –99999.000 to +99999.000) AIx01HW2 :=
AI
x01 HI ALARM (OFF, –99999.000 to +99999.000) AIx01HAL :=
AIx02
AIx02 TAG NAME (8 characters 0–9, A–Z, _) AIx02NAM :=
AI
x02 TYPE (I, V) AIx02TYP :=
