SEL-787 Settings Sheets
Global Settings (SET G Command)
Date _______________
Group______________
SEL-787 Relay Instruction Manual Date Code 20150130
AIx04 HI IN VAL (–20.480 to +20.480; mA) AIx04H :=
If AI
x04TYP = V
AI
x04 LOW IN VAL (–10.240 to +10.240 V) AIx04L :=
AI
x04 HI IN VAL (–10.240 to +10.240 V) AIx04H :=
AI
x04 ENG UNITS (16 characters) AIx04EU :=
AI
x04 EU LOW (–99999.000 to +99999.000) AIx04EL :=
AI
x04 EU HI (–99999.000 to +99999.000) AIx04EH :=
AI
x04 LO WARN L1 (OFF, –99999.000 to +99999.000) AIx04LW1 :=
AI
x04 LO WARN L2 (OFF, –99999.000 to +99999.000) AIx04LW2 :=
AI
x04 LO ALARM (OFF, –99999.000 to +99999.000) AIx04LAL :=
AI
x04 HI WARN L1 (OFF, –99999.000 to +99999.000) AIx04HW1 :=
AI
x04 HI WARN L2 (OFF, –99999.000 to +99999.000) AIx04HW2 :=
AI
x04 HI ALARM (OFF, –99999.000 to +99999.000) AIx04HAL :=
Analog Outputs
For the following settings, x is the card position (3, 4, or 5 in Slot C, D, and E, respectively).
AOx01
AOx01 ANALOG QTY (Off, 1 analog quantity) AOx01AQ :=
AO
x01 TYPE (I, V) AOx01TYP :=
AO
x01 AQTY LOW (–2147483647 to +2147483647) AOx01AQL :=
AO
x01 AQTY HI (–2147483647 to +2147483647) AOx01AQH :=
If AO
x01TYP = I
AO
x01 LO OUT VAL (–20.480 to +20.480 mA) AOx01L :=
AO
x01 HI OUT VAL (–20.480 to +20.480 mA) AOx01H :=
If AO
x01TYP = V
AO
x01 LO OUT VAL (–10.240 to +10.240 V) AOx01L :=
AO
x01 HI OUT VAL (–10.240 to +10.240 V) AOx01H :=
AOx02
AOx02 ANALOG QTY (Off, 1 analog quantity) AOx02AQ :=
AO
x02 TYPE (I, V) AOx02TYP :=
AO
x02 AQTY LOW (–2147483647 to +2147483647) AOx02AQL :=
AO
x02 AQTY HI (–2147483647 to +2147483647) AOx02AQH :=
If AO
x02TYP = I
AO
x02 LO OUT VAL (–20.480 to +20.480 mA) AOx02L :=
AO
x02 HI OUT VAL (–20.480 to +20.480 mA) AOx02H :=
If AO
x02TYP = V
AO
x02 LO OUT VAL (–10.240 to +10.240 V) AOx02L :=
AO
x02 HI OUT VAL (–10.240 to +10.240 V) AOx02H :=
