Sel SEL-787 - Page 255

Date _______________
Group______________
SET.33
of 66
SEL-787 Settings Sheets
Global Settings (SET G Command)
Date Code 20150130 Instruction Manual SEL-787 Relay
AOx03
AOx03 ANALOG QTY (Off, 1 analog quantity) AOx03AQ :=
AO
x03 TYPE (I, V) AOx03TYP :=
AO
x03 AQTY LOW (–2147483647 to +2147483647) AOx03AQL :=
AO
x03 AQTY HI (–2147483647 to +2147483647) AOx03AQH :=
If AO
x03TYP = I
AO
x03 LO OUT VAL (–20.480 to +20.480 mA) AOx03L :=
AO
x03 HI OUT VAL (–20.480 to +20.480 mA) AOx03H :=
If AO
x03TYP = V
AO
x03 LO OUT VAL (–10.240 to +10.240 V) AOx03L :=
AO
x03 HI OUT VAL (–10.240 to +10.240 V) AOx03H :=
AOx04
AOx04 ANALOG QTY (Off, 1 analog quantity) AOx04AQ :=
AO
x04 TYPE (I, V) AOx04TYP :=
AO
x04 AQTY LOW (–2147483647 to +2147483647) AOx04AQL :=
AO
x04 AQTY HI (–2147483647 to +2147483647) AOx04AQH :=
If AO
x04TYP = I
AO
x04 LO OUT VAL (–20.480 to +20.480 mA) AOx04L :=
AO
x04 HI OUT VAL (–20.480 to +20.480 mA) AOx04H :=
If AO
x04TYP = V
AO
x04 LO OUT VAL (–10.240 to +10.240 V) AOx04L :=
AO
x04 HI OUT VAL (–10.240 to +10.240 V) AOx04H :=
Input Debounce Settings (Base Unit)
IN101 Debounce (AC, 0–65000 ms) IN101D :=
IN102 Debounce (AC, 0–65000 ms)
IN102D :=
Input Debounce Settings (Slot C)
IN301 Debounce (AC, 0–65000 ms) IN301D :=
IN302 Debounce (AC, 0–65000 ms)
IN302D :=
IN303 Debounce (AC, 0–65000 ms)
IN303D :=
IN304 Debounce (AC, 0–65000 ms)
IN304D :=
IN305 Debounce (AC, 0–65000 ms)
IN305D :=
IN306 Debounce (AC, 0–65000 ms)
IN306D :=
IN307 Debounce (AC, 0–65000 ms)
IN307D :=
IN308 Debounce (AC, 0–65000 ms)
IN308D :=
