SEL-787 Settings Sheets
Global Settings (SET G Command)
Date _______________
Group______________
SEL-787 Relay Instruction Manual Date Code 20150130
Input Debounce Settings (Slot D)
IN401 Debounce (AC, 0–65000 ms) IN401D :=
IN402 Debounce (AC, 0–65000 ms)
IN402D :=
IN403 Debounce (AC, 0–65000 ms)
IN403D :=
IN404 Debounce (AC, 0–65000 ms)
IN404D :=
IN405 Debounce (AC, 0–65000 ms)
IN405D :=
IN406 Debounce (AC, 0–65000 ms)
IN406D :=
IN407 Debounce (AC, 0–65000 ms)
IN407D :=
IN408 Debounce (AC, 0–65000 ms)
IN408D :=
Input Debounce Settings (Slot E)
IN501 Debounce (AC, 0–65000 ms) IN501D :=
IN502 Debounce (AC, 0–65000 ms)
IN502D :=
IN503 Debounce (AC, 0–65000 ms)
IN503D :=
IN504 Debounce (AC, 0–65000 ms)
IN504D :=
IN505 Debounce (AC, 0–65000 ms)
IN505D :=
IN506 Debounce (AC, 0–65000 ms)
IN506D :=
IN507 Debounce (AC, 0–65000 ms)
IN507D :=
IN508 Debounce (AC, 0–65000 ms)
IN508D :=
Data Reset
RESET TARGETS (SELOGIC) RSTTRGT :=
RESET ENERGY (SEL
OGIC) RSTENRGY:=
RESET MAX/MIN (SEL
OGIC) RSTMXMN:=
RESET DEMAND ((SEL
OGIC) RSTDEM :=
RESET PK DEMAND ((SEL
OGIC) RSTPKDEM:=
Access Control
DISABLE SETTINGS (SELOGIC) DSABLSET:=
BLOCK MODBUS SET (NONE, R_S, ALL)
BLKMBSET:=
Time Synchronization Source
IRIG TIME SOURCE (IRIG1, IRIG2) TIME_SRC :=
