SEL-787 Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
Date _______________
Group______________
SEL-787 Relay Instruction Manual Date Code 20150130
TELNET TIME-OUT (1–30 min) TIDLE :=
FTP USER NAME (20 characters)
FTPUSER :=
Enable IEC 61850 Protocol (Y, N)
(Hidden if 61850 not supported) E61850 :=
Enable IEC 61850 GSE (Y, N)
(Hidden if E61850 := N) EGSE :=
Enable Modbus Sessions (0–2)
EMOD :=
Modbus TCP Port1 (1–65534)
(Hidden if EMOD := 0)
(NOTE: See Table SET.1 and the note at the end of Port 1 settings)
MODNUM1:=
Modbus TCP Port2 (1–65534)
(Hidden if EMOD := 0 or 1)
(NOTE: See Table SET.1 and the note at the end of Port 1 settings)
MODNUM2:=
Modbus Timeout 1 (15–900 sec)
(Hidden if EMOD := 0) MTIMEO1 :=
Modbus Timeout 2 (15–900 sec)
(Hidden if EMOD := 0 or 1) MTIMEO2 :=
DNP3 Protocol
All DNP3 settings below are hidden if DNP3 is not an option.
Enable DNP3 Sessions (0–3)
(DNP3 settings below
hidden if EDNP := 0) EDNP :=
DNP TCP and UDP Port (1–65534)
(NOTE: See Table SET.1 and the note at the end of Port 1 settings)
DNPNUM :=
DNP Address (0–65519)
DNPADR :=
Session 1
NOTE: The DNP IP address of each session (DNPIP1, DNPIP2, etc.) must be unique
IP Address [zzz.yyy.xxx.www] (15 characters)
DNPIP1 :=
Transport Protocol (UDP, TCP)
DNPTR1 :=
UDP Response Port (REQ, 1–65534)
DNPUDP1 :=
DNP Address to Report to (0–65519)
REPADR1 :=
DNP Map (1–3)
DNPMAP1 :=
Analog Input Default Variation (1–6)
DVARAI1 :=
Class for Binary Event Data (0–3)
ECLASSB1 :=
Class for Counter Event Data (0–3)
ECLASSC1 :=
Class for Analog Event Data (0–3)
ECLASSA1 :=
Currents Scaling Decimal Places (0–3)
DECPLA1 :=
Voltages Scaling Decimal Places (0–3)
DECPLV1 :=
Misc Data Scaling Decimal Places (0–3)
DECPLM1 :=
Amps Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA1 := 0)
ANADBA1 :=
Volts Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA1 := 0)
ANADBV1 :=
Misc Data Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA1 := 0 and ECLASSC1 := 0)
ANADBM1 :=
Minutes for Request Interval (I, M, 1–32767)
TIMERQ1 :=
Seconds to Select/Operate Time-Out (0.0–30.0)
STIMEO1 :=
