Date _______________
Group______________
SET.37
of 66
SEL-787 Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
Date Code 20150130 Instruction Manual SEL-787 Relay
Seconds to send Data Link Heartbeat (0–7200)
(Hidden if DNPTR1 := UDP)
DNPINA1 :=
Event Message Confirm Time-Out (1–50 sec))
ETIMEO1 :=
Enable Unsolicited Reporting (Y, N)
(Hidden if ECLASSA1 := 0, ECLASSB1 := 0, ECLASSC1 := 0, and
ECLASSV1 := 0)
UNSOL1 :=
Enable Unsolicited Reporting at Power-Up (Y, N)
(Hidden if UNSOL1 := N)
PUNSOL1 :=
Number of Events to Transmit On (1–200)
(Hidden if UNSOL1 := N)
NUMEVE1 :=
Oldest Event to Tx On (0.0–99999.0 sec)
(Hidden if UNSOL1 := N)
AGEEVE1 :=
Unsolicited Message Max Retry Attempts (2–10)
(Hidden if UNSOL1 := N)
URETRY1 :=
Unsolicited Message Offline Time-Out (1–5000 sec)
(Hidden if UNSOL1 := N)
UTIMEO1 :=
Session 2
All Session 2 settings are hidden if EDNP < 2.
IP Address [zzz.yyy.xxx.www] (15 characters)
DNPIP2 :=
Transport Protocol (UDP, TCP)
DNPTR2 :=
UDP Response Port (REQ, 1
–65534) DNPUDP2 :=
DNP Address to Report to (0
–65519) REPADR2 :=
DNP Map (1–3)
DNPMAP2 :=
Analog Input Default Variation (1–6)
DVARAI2 :=
Class for Binary Event Data (0–3)
ECLASSB2 :=
Class for Counter Event Data (0–3)
ECLASSC2 :=
Class for Analog Event Data (0–3)
ECLASSA2 :=
Currents Scaling Decimal Places (0–3)
DECPLA2 :=
Voltages Scaling Decimal Places (0–3)
DECPLV2 :=
Misc Data Scaling Decimal Places (0–3)
DECPLM2 :=
Amps Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA2 := 0)
ANADBA2 :=
Volts Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA2 := 0)
ANADBV2 :=
Misc Data Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA2 := 0 and ECLASSC2 := 0)
ANADBM2 :=
Minutes for Request Interval (I, M, 1–32767)
TIMERQ2 :=
Seconds to Select/Operate Time-Out (0.0–30.0)
STIMEO2 :=
Seconds to send Data Link Heartbeat (0–7200)
(Hidden if DNPTR2 := UDP)
DNPINA2 :=
Event Message Confirm Time-Out (1–50 sec))
ETIMEO2 :=
Enable Unsolicited Reporting (Y, N)
(Hidden if ECLASSA2 := 0, ECLASSB2 := 0, ECLASSC2 := 0, and
ECLASSV2 := 0)
UNSOL2 :=
