SEL-787 Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
Date Code 20150130 Instruction Manual SEL-787 Relay
Volts Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA1 := 0)
ANADBV1 :=
Misc Data Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA1 := 0 and ECLASSC1 := 0)
ANADBM1 :=
Minutes for Request Interval (I, M, 1–32767)
TIMERQ1 :=
Seconds to Select/Operate Time-Out (0.0–30.0)
STIMEO1 :=
Data Link Retries (0–15)
DRETRY1 :=
Seconds to Data Link Time-Out (0–5)
(Hidden if DRETRY1 := 0)
DTIMEO1 :=
Event Message Confirm Time-Out (1–50 sec))
ETIMEO1 :=
Enable Unsolicited Reporting (Y, N)
(Hidden if ECLASSA1 := 0, ECLASSB1 := 0, ECLASSC1 := 0, and
ECLASSV1 := 0)
UNSOL1 :=
Enable Unsolicited Reporting at Power-Up (Y, N)
(Hidden if UNSOL1 := N)
PUNSOL1 :=
Number of Events to Transmit On (1–200)
(Hidden if UNSOL1 := N)
NUMEVE1 :=
Oldest Event to Tx On (0.0–99999.0 sec)
(Hidden if UNSOL1 := N)
AGEEVE1 :=
Unsolicited Message Max Retry Attempts (2–10)
(Hidden if UNSOL1 := N)
URETRY1 :=
Unsolicited Message Offline Time-Out (1–5000 sec)
(Hidden if UNSOL1 := N)
UTIMEO1 :=
Minimum Seconds from DCD to TX (0.00–1.00)
MINDLY :=
Maximum Seconds from DCD to TX (0.00–1.00)
MAXDLY :=
Settle Time from RTS On to TX (OFF, 0.00–30.00 sec)
PREDLY :=
Settle Time from TX to RTS OFF (0.00–30.00 sec)
PSTDLY :=
Modem Protocol (for DNP3 session and EIA232 port only)
Modem Connected to Port (Y, N) MODEM :=
Modem Startup String (30 characters)
MSTR :=
Phone Number for Dial-Out (30 characters)
PH_NUM1 :=
Phone Number for Dial-Out (30 characters)
PH_NUM2 :=
Retry Attempts for Phone 1 Dial-Out (1–20)
RETRY1 :=
Retry Attempts for Phone 2 Dial-Out (1–20)
RETRY2 :=
Time to Attempt Dial (5–300 sec)
MDTIME :=
Time Between Dial-Out Attempts (5–3600 sec)
MDRET :=
Modbus Protocol
MODBUS SLAVE ID (1–247) (Hidden if PROTO := SEL, DNP,
PMU, EVMSG, MB_, or DNET)
SLAVEID :=
MIRRORED BITS Protocol
(Hidden if PROTO := SEL, EVMSG, DNP, PMU, DNET or MOD.)
MB Transmit Identifier (1–4) TXID :=
