SEL-787 Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
Date _______________
Group______________
SEL-787 Relay Instruction Manual Date Code 20150130
MB Receive Identifier (1–4) RXID :=
MB RX Bad Pickup Time (0–10000 seconds)
RBADPU :=
MB Channel Bad Pickup (1–10000 ppm)
CBADPU :=
MB Receive Default State (8 characters)
RXDFLT :=
RMB1 Pickup Debounce Messages (1–8)
RMB1PU :=
RMB1 Dropout Debounce Messages (1–8)
RMB1DO :=
RMB2 Pickup Debounce Messages (1–8)
RMB2PU :=
RMB2 Dropout Debounce Messages (1–8)
RMB2DO :=
RMB3 Pickup Debounce Messages (1–8)
RMB3PU :=
RMB3 Dropout Debounce Messages (1–8)
RMB3DO :=
RMB4 Pickup Debounce Messages (1–8)
RMB4PU :=
RMB4 Dropout Debounce Messages (1–8)
RMB4DO :=
RMB5 Pickup Debounce Messages (1–8)
RMB5PU :=
RMB5 Dropout Debounce Messages (1–8)
RMB5DO :=
RMB6 Pickup Debounce Messages (1–8)
RMB6PU :=
RMB6 Dropout Debounce Messages (1–8)
RMB6DO :=
RMB7 Pickup Debounce Messages (1–8)
RMB7PU :=
RMB7 Dropout Debounce Messages (1–8)
RMB7DO :=
RMB8 Pickup Debounce Messages (1–8)
RMB8PU :=
RMB8 Dropout Debounce Messages (1–8)
RMB8DO :=
