SEL-787 Settings Sheets
Front-Panel Settings (SET F Command)
Date Code 20150130 Instruction Manual SEL-787 Relay
Front-Panel Settings (SET F Command)
General
DISPLY PTS ENABL (N, 1–32) EDP :=
LOCAL BITS ENABL (N, 1–32)
ELB :=
LCD TIMEOUT (OFF, 1–30 min)
FP_TO :=
LCD CONTRAST (1–8)
FP_CONT :=
FP AUTOMESSAGES (OVERRIDE, ROTATING)
FP_AUTO :=
CLOSE RESET LEDS (Y, N)
RSTLED :=
Target LED
TRIP LATCH T_LED (Y, N) T01LEDL :=
LED1 EQUATION (SEL
OGIC) T01_LED :=
TRIP LATCH T_LED (Y, N)
T02LEDL :=
LED2 EQUATION (SEL
OGIC) T02_LED :=
TRIP LATCH T_LED (Y, N)
T03LEDL :=
LED3 EQUATION (SEL
OGIC) T03_LED :=
TRIP LATCH T_LED (Y, N)
T04LEDL :=
LED4 EQUATION (SEL
OGIC) T04_LED :=
TRIP LATCH T_LED (Y, N)
T05LEDL :=
LED5 EQUATION (SEL
OGIC) T05_LED :=
TRIP LATCH T_LED (Y, N)
T06LEDL :=
LED6 EQUATION (SEL
OGIC) T06_LED :=
PB1A_LED EQUATION (SEL
OGIC) PB1A_LED :=
PB1B_LED EQUATION (SEL
OGIC) PB1B_LED :=
PB2A_LED EQUATION (SEL
OGIC) PB2A_LED :=
PB2B_LED EQUATION (SEL
OGIC) PB2B_LED :=
PB3A_LED EQUATION (SEL
OGIC) PB3A_LED :=
PB3B_LED EQUATION (SEL
OGIC) PB3B_LED :=
PB4A_LED EQUATION (SEL
OGIC) PB4A_LED :=
PB4B_LED EQUATION (SEL
OGIC) PB4B_LED :=
Display Points
Display Point Settings (maximum 60 characters):
➤ (Boolean): Relay Word Bit Name, "Alias", "Set String", "Clear String"
➤ (Analog): Analog Quantity Name, "User Text and Formatting"
DISPLAY POINT DP01 (60 characters)
DP01 :=
DISPLAY POINT DP02 (60 characters)
DP02 :=
