Sel SEL-787 - Page 440

D.16
SEL-787 Relay Instruction Manual Date Code 20150130
DNP3 Communications
DNP3 Documentation
31 7 Short Floating Point Frozen Analog Input
31 8 Long Floating Point Frozen Analog Input
32 0 Analog Change Event—All Variations 1 6, 7, 8
32
f
1 32-Bit Analog Change Event Without Time 1 6, 7, 8 129 17, 28
32
f
2 16-Bit Analog Change Event Without Time 1 6, 7, 8 129, 130 17, 28
32
f
3 32-Bit Analog Change Event With Time 1 6, 7, 8 129 17, 28
32
f
4 16-Bit Analog Change Event With Time 1 6, 7, 8 129 17, 28
32
f
5 Short Floating Point Analog Change Event 1 6, 7, 8 129 17, 28
32
f
6 Long Floating Point Analog Change Event 1 6, 7, 8 129 17, 28
32
f
7 Short Floating Point Analog Change Event With Time 1 6, 7, 8 129 17, 28
32
f
8 Long Floating Point Analog Change Event With Time 1 6, 7, 8 129 17, 28
33 0 Frozen Analog Event—All Variations
33 1 32-Bit Frozen Analog Event Without Time
33 2 16-Bit Frozen Analog Event Without Time
33 3 32-Bit Frozen Analog Event With Time
33 4 16-Bit Frozen Analog Event With Time
33 5 Short Floating Point Frozen Analog Event
33 6 Long Floating Point Frozen Analog Event
33 7 Short Floating Point Frozen Analog Event With Time
33 8 Long Floating Point Frozen Analog Event With Time
34 0 Analog Dead Band—All Variations
34 1
e
16-Bit Analog Input Reporting Dead-band Object 1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
34 2 32-Bit Analog Input Reporting Dead-band Object 1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
34 3 Floating Point Analog Input Reporting Dead-band Object 1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
40 0 Analog Output Status—All Variations 1 0, 1, 6, 7, 8 129
40 1 32-Bit Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 2
e
16-Bit Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 3 Short Floating Point Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 4 Long Floating Point Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
41 0 Analog Output Block—All Variations
41 1 32-Bit Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
41 2
e
16-Bit Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
41 3 Short Floating Point Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
50 0 Time and Date—All Variations
50 1 Time and Date 1, 2 7, 8 index=0 129 07, quantity=1
50 2 Time and Date With Interval
50 3 Time and Date Last Recorded 2 7 quantity = 1 129
51 0 Time and Date CTO—All Variations
51 1 Time and Date CTO
51 2 Unsynchronized Time and Date CTO 129 07, quantity=1
Table D.9 SEL- 787 D N P O bject List (Sheet 4 of 5)
Obj. Var. Description
Request
a
Response
b
Funct.
Codes
c
Qual.
Codes
d
Funct.
Codes
c
Qual.
Codes
d
