Date Code 20150130 Instruction Manual SEL-787 Relay
DNP3 Communications
DNP3 Documentation
52 0 Time Delay—All Variations
52 1 Time Delay, Coarse
52 2 Time Delay, Fine 129 7, quantity=1
60 0 All Classes of Data 1, 20, 21 6, 7, 8
60 1 Class 0 Data 1, 20, 21 6, 7, 8
60 2 Class 1 Data 1 6, 7, 8
60 3 Class 2 Data 1, 20, 21 6, 7, 8
60 4 Class 3 Data 1, 20, 21 6, 7, 8
70 1 File Identifier
70 2 Authentication Object
70 3 File Command Object
70 4 File Command Status Object
70 5 File Transport Object
70 6 File Transport Status Object
70 7 File Descriptor Object
80 1 Internal Indications 2 0, 1 index=7
81 1 Storage Object
82 1 Device Profile
83 1 Private Registration Object
83 2 Private Registration Object Descriptor
90 1 Application Identifier
100 1 Short Floating Point
100 2 Long Floating Point
100 3 Extended Floating Point
101 1 Small Packed Binary-Coded Decimal
101 2 Medium Packed Binary-Coded Decimal
101 3 Large Packed Binary-Coded Decimal
110 all Octet String
111 all Octet String Event
112 All Virtual Terminal Output Block
113 All Virtual Terminal Event Data
N/A No object required for the following function codes:
13 cold start
14 warm start
23 delay measurement
13, 14, 23
a
Supported in requests from master.
b
May generate in response to master.
c
Decimal.
d
Hexadecimal.
e
Default variation.
f
Default variation specified by serial port setting DVARAI (or DVARAIn for Ethernet session n [n = 1, 2, or 3]).
Table D.9 SEL- 787 D N P O bject List (Sheet 5 of 5)
Obj. Var. Description
Request
a
Response
b
Funct.
Codes
c
Qual.
Codes
d
Funct.
Codes
c
Qual.
Codes
d
