E.49
Date Code 20150130 Instruction Manual SEL-787 Relay
Modbus RTU Communications
Modbus Register Map
Bit 6 = 51P2T
Bit 7 = 51P1T
1147 (R) ROW 5 0 255 0 1247
Bit 0 = 87R
Bit 1 = 87R3
Bit 2 = 87R2
Bit 3 = 87R1
Bit 4 = 87U
Bit 5 = 87U3
Bit 6 = 87U2
Bit 7 = 87U1
1148 (R) ROW 6 0 255 0 1248
Bit 0 = 3PWR2T
Bit 1 = 3PWR1T
Bit 2 = 59P2T
Bit 3 = 59P1T
Bit 4 = 27P2T
Bit 5 = 27P1T
Bit 6 = 87AT
Bit 7 = TH5T
1149 (R) ROW 7 0 255 0 1249
Bit 0 = 59Q2T
Bit 1 = 59Q1T
Bit 2 = BFT2
Bit 3 = BFT1
Bit 4 = 81D4T
Bit 5 = 81D3T
Bit 6 = 81D2T
Bit 7 = 81D1T
1150 (R) ROW 8 0 255 0 1250
Bit 0 = RTDT
Bit 1 = *
Bit 2 = *
Bit 3 = 24CR
Bit 4 = 24C2T
Bit 5 = 24C2
Bit 6 = 24D1T
Bit 7 = 24D1
1151 (R) ROW 9 0 255 0 1251
Bit 0 = ORED51T
Bit 1 = ORED50T
Bit 2 = *
Bit 3 = *
Bit 4 = *
Bit 5 = *
Bit 6 = *
Bit 7 = REMTRIP
1152 (R) ROW 10 0 255 0 1252
Bit 0 = 50P24P
Bit 1 = 50P23P
Bit 2 = 50P22P
Bit 3 = 50P21P
Bit 4 = 50P14P
Bit 5 = 50P13P
Bit 6 = 50P12P
Bit 7 = 50P11P
1153 (R) ROW 11 0 255 0 1253
Bit 0 = 50Q22P
Bit 1 = 50Q21P
Bit 2 = 50G22P
Bit 3 = 50G21P
Bit 4 = 50Q12P
Bit 5 = 50Q11P
Bit 6 = 50G12P
Bit 7 = 50G11P
Table E.34 Modbus Register Map
a
(Sheet 27 of 36)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fac tor
DeviceNet
Parameter
Numbers
To Next Page
