E.50
SEL-787 Relay Instruction Manual Date Code 20150130
Modbus RTU Communications
Modbus Register Map
1154 (R) ROW 12 0 255 0 1254
Bit 0 = 52A2
Bit 1 = 52A1
Bit 2 = 51P2AR
Bit 3 = 51P1CR
Bit 4 = 51P1BR
Bit 5 = 51P1AR
Bit 6 = 50N12P
Bit 7 = 50N11P
1155 (R) ROW 13 0 255 0 1255
Bit 0 = 51P2BR
Bit 1 = 51N1P
Bit 2 = 51Q2P
Bit 3 = 51Q1P
Bit 4 = 51G2P
Bit 5 = 51G1P
Bit 6 = 51P2P
Bit 7 = 51P1P
1156 (R) ROW 14 0 255 0 1256
Bit 0 = 51P2CR
Bit 1 = 51N1R
Bit 2 = 51Q2R
Bit 3 = 51Q1R
Bit 4 = 51G2R
Bit 5 = 51G1R
Bit 6 = 51P2R
Bit 7 = 51P1R
1157 (R) ROW 15 0 255 0 1257
Bit 0 = 5HBL
Bit 1 = 5HB3
Bit 2 = 5HB2
Bit 3 = 5HB1
Bit 4 = 2_4HBL
Bit 5 = 2_4HB3
Bit 6 = 2_4HB2
Bit 7 = 2_4HB1
1158 (R) ROW 16 0 255 0 1258
Bit 0 = 87HR
Bit 1 = 87HR3
Bit 2 = 87HR2
Bit 3 = 87HR1
Bit 4 = 87HB
Bit 5 = 87BL3
Bit 6 = 87BL2
Bit 7 = 87BL1
1159 (R) ROW 17 0 255 0 1259
Bit 0 = 3PWR2P
Bit 1 = 3PWR1P
Bit 2 = 59P2
Bit 3 = 59P1
Bit 4 = 27P2
Bit 5 = 27P1
Bit 6 = 87AP
Bit 7 = TH5
1160 (R) ROW 18 0 255 0 1260
Bit 0 = 59Q2
Bit 1 = 59Q1
Bit 2 = BFI2
Bit 3 = BFI1
Bit 4 = OTHTRIP
Bit 5 = OTHALRM
Bit 6 = AMBTRIP
Bit 7 = AMBALRM
1161 (R) ROW 19 0 255 0 1261
Bit 0 = OUT304
Bit 1 = OUT303
Bit 2 = OUT302
Table E.34 Modbus Register Map
a
(Sheet 28 of 36)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fac tor
DeviceNet
Parameter
Numbers
To Next Page
