E.51
Date Code 20150130 Instruction Manual SEL-787 Relay
Modbus RTU Communications
Modbus Register Map
Bit 3 = OUT301
Bit 4 = OUT103
Bit 5 = OUT102
Bit 6 = OUT101
Bit 7 = TRIP
1162 (R) ROW 20 0 255 0 1262
Bit 0 = OUT504
Bit 1 = OUT503
Bit 2 = OUT502
Bit 3 = OUT501
Bit 4 = OUT404
Bit 5 = OUT403
Bit 6 = OUT402
Bit 7 = OUT401
1163 (R) ROW 21 0 255 0 1263
Bit 0 = IN108
Bit 1 = *
Bit 2 = *
Bit 3 = *
Bit 4 = *
Bit 5 = *
Bit 6 = IN102
Bit 7 = IN101
1164 (R) ROW 22 0 255 0 1264
Bit 0 = IN308
Bit 1 = IN307
Bit 2 = IN306
Bit 3 = IN305
Bit 4 = IN304
Bit 5 = IN303
Bit 6 = IN302
Bit 7 = IN301
1165 (R) ROW 23 0 255 0 1265
Bit 0 = IN408
Bit 1 = IN407
Bit 2 = IN406
Bit 3 = IN405
Bit 4 = IN404
Bit 5 = IN403
Bit 6 = IN402
Bit 7 = IN401
1166 (R) ROW 24 0 255 0 1266
Bit 0 = IN508
Bit 1 = IN507
Bit 2 = IN506
Bit 3 = IN505
Bit 4 = IN504
Bit 5 = IN503
Bit 6 = IN502
Bit 7 = IN501
1167 (R) ROW 25 0 255 0 1267
Bit 0 = FAULT
Bit 1 = IRIGOK
Bit 2 = TSOK
Bit 3 = WARNING
Bit 4 = SALARM
Bit 5 = PMDOK
Bit 6 = LINKBOK
Bit 7 =LINKAOK
Table E.34 Modbus Register Map
a
(Sheet 29 of 36)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fac tor
DeviceNet
Parameter
Numbers
