E.52
SEL-787 Relay Instruction Manual Date Code 20150130
Modbus RTU Communications
Modbus Register Map
1168 (R) ROW 26 0 255 0 1268
Bit 0 = LOP
Bit 1 = *
Bit 2 = *
Bit 3 = *
Bit 4 = CFGFLT
Bit 5 = COMMFLT
Bit 6 = COMMLOSS
Bit 7 = COMMIDLE
1169 (R) ROW 27 0 255 0 1269
Bit 0 = RSTPKDEM
Bit 1 = RSTDEM
Bit 2 = RSTMXMN
Bit 3 = RSTENRGY
Bit 4 = *
Bit 5 = *
Bit 6 = ER
Bit 7 = FREQTRK
1170 (R) ROW 28 0 255 0 1270
Bit 0 = HALARM
Bit 1 = RSTTRGT
Bit 2 = DSABLSET
Bit 3 = *
Bit 4 = RTDA
Bit 5 = TRGTR
Bit 6 = RTDIN
Bit 7 = RTDFLT
1171 (R) ROW 29 0 255 0 1271
•
•
•
•
•
•
1248 (R) ROW 106 0 255 0 1348
1249–1270 (R) Reserved
c
0 0 0 1349—1370
Extra Settings
WDG1 Per Ph TOC
1271 (RW) W1 PH-A TOC EN 0 1 0 1371
0 = N
1 = Y
1272 (RW) W1 PH-A TOC LVL A 10 1600 120 0.01 1372
1273 (RW) W1 PHA TOC CURVE 0 9 2 1 1373
0 = U1 5 = C1
1 = U2 6 = C2
2 = U3 7 = C3
3 = U4 8 = C4
4 = U5 9 = C5
1274 (RW) W1 PHA TOC TDIAL 5 1500 300 0.01 1374
1275 (RW) W1 PHA EMRST DLY 0 1 0 1375
0 = N
1 = Y
1276 (RW) W1 PHA CONST TIM sec 0 100 0 0.01 1376
1277 (RW) W1 PHA MIN TIM sec 0 100 0 0.01 1377
1278 (RW) W1 PH-B TOC EN 0 1 0 1378
0 = N
1 = Y
1279 (RW) W1 PH-B TOC LVL A 10 1600 120 0.01 1379
1280 (RW) W1 PHB TOC CURVE 0 9 2 1 1380
0 = U1 5 = C1
1 = U2 6 = C2
Table E.34 Modbus Register Map
a
(Sheet 30 of 36)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fac tor
DeviceNet
Parameter
Numbers
