Sel SEL-787 - Page 505

E.53
Date Code 20150130 Instruction Manual SEL-787 Relay
Modbus RTU Communications
Modbus Register Map
2 = U3 7 = C3
3 = U4 8 = C4
4 = U5 9 = C5
1281 (RW) W1 PHB TOC TDIAL 5 1500 300 0.01 1381
1282 (RW) W1 PHB EMRST DLY 0 1 0 1382
0 = N
1 = Y
1283 (RW) W1 PHB CONST TIM sec 0 100 0 0.01 1383
1284 (RW) W1 PHB MIN TIM sec 0 100 0 0.01 1384
1285 (RW) W1 PH-C TOC EN 0 1 0 1385
0 = N
1 = Y
1286 (RW) W1 PH-C TOC LVL A 10 1600 120 0.01 1386
1287 (RW) W1 PHC TOC CURVE 0 9 2 1 1387
0 = U1 5 = C1
1 = U2 6 = C2
2 = U3 7 = C3
3 = U4 8 = C4
4 = U5 9 = C5
1288 (RW) W1 PHC TOC TDIAL 5 1500 300 0.01 1388
1289 (RW) W1 PHC EMRST DLY 0 1 0 1389
0 = N
1 = Y
1290 (RW) W1 PHC CONST TIM sec 0 100 0 0.01 1390
1291 (RW) W1 PHC MIN TIM sec 0 100 0 0.01 1391
WDG2 Per Ph TOC
1292 (RW) W2 PH-A TOC EN 0 1 0 1392
0 = N
1 = Y
1293 (RW) W2 PH-A TOC LVL A 10 1600 120 0.01 1393
1294 (RW) W2 PHA TOC CURVE 0 9 2 1 1394
0 = U1 5 = C1
1 = U2 6 = C2
2 = U3 7 = C3
3 = U4 8 = C4
4 = U5 9 = C5
1295 (RW) W2 PHA TOC TDIAL 5 1500 300 0.01 1395
1296 (RW) W2 PHA EMRST DLY 0 1 0 1396
0 = N
1 = Y
1297 (RW) W2 PHA CONST TIM sec 0 100 0 0.01 1397
1298 (RW) W2 PHA MIN TIM sec 0 100 0 0.01 1398
1299 (RW) W2 PH-B TOC EN 0 1 0 1399
0 = N
1 = Y
1300 (RW) W2 PH-B TOC LVL A 10 1600 120 0.01 1400
1301 (RW) W2 PHB TOC CURVE 0 9 2 1 1401
0 = U1 5 = C1
1 = U2 6 = C2
2 = U3 7 = C3
3 = U4 8 = C4
4 = U5 9 = C5
1302 W2 PHB TOC TDIAL 5 1500 300 0.01 1402
Table E.34 Modbus Register Map
a
(Sheet 31 of 36)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fac tor
DeviceNet
Parameter
Numbers
