VISOR
®
Communications manual
Auto operating distance (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Auto operating distance (ASCII) request string to sensor
Byte no. Content Meaning
1 A
Auto Focus2 F
3 C
4 1 Request version
5 X
0: Temporary
1: Permanent
6 X Step size 1 -5
7 - 9 X
Focus selection
0 - Maximum score
1 - Min. Operating distance
2 - Max. operating distance
3 - Operating distance average
4 - Operating distance median
5 - Maximum score and all planes
10 X
Focus unit
0 - Millimeter
1 - Steps
11 X
Range flag
0 - Default Range
1 - Specified Range
NOTE:
The following byte sequence is only relevant if "Distance
range selection" has been set to 1.
12 - 19 X Range min in Specified Unit
20 - 27 X Range max Specified Unit
Example:
Example 1: AFC1100500
Example 2: AFC11005010001000000100000
Page 101 EN 06814859 - 1/24/2019-00
