Sensopart Visor - Visualization

VISOR
®
Communications manual
l Calibration: Read parameter (ASCII / Binary)
With the telegram "Calibration: Read parameter", the set parameter values of the
calibration can be read.
VISOR
®
Visualization
l Get image (ASCII / Binary)
The "Get image" telegram can be used to get the image from the VISOR
®
vision sensor.
VISOR
®
Service (available only on port 1998 and in ASCII format)
l Update visualization results (ASCII)
With the telegram "Update visualization results", the visualization results, e.g. image,
detector information, and results, are updated.
l Read sensor identity (ASCII)
With the telegram "Read sensor identity", the current firmware status as well as the
hardware type can be queried.
l Update firmware (ASCII)
With the telegram "Update firmware", a firmware update is started. The firmware file must
first be loaded onto the VISOR
®
vision sensor.
l Read job set (ASCII)
The "Import job set" telegram can be used to change the VISOR
®
vision sensor’s job set.
The job set file must first be loaded onto the VISOR
®
.
l Save job set (ASCII)
The "Back up job set" telegram can be used to read the VISOR
®
vision sensor’s job set.
Data output
(ASCII / Binary)
This section provides information about the data output. In particular which format the individual
results receive.
Telegrams: Availability and supported interfaces (Page 85)
06814859 - 1/24/2019-00 Page 84 EN
