VISOR
®
Communications manual
Read job list (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Read job list (binary) request string to sensor
Byte no. Data type Content Meaning
1 - 4
Unsigned
Int
0x05 Telegram length
5
Unsigned
Char
0x14 Get Job List
Read job list (binary) response string from sensor
Byte no. Data type Content Meaning
1 - 4
Unsigned
Int
0xXX Telegram length
5
Unsigned
Char
0x14 Get Job List
6
Unsigned
Short
0xXX Error codes (Page 88)
8
Unsigned
Char
0x01 Constant
9
Unsigned
Char
0xXX Number of jobs
10
Unsigned
Char
0xXX Active job number
NOTE:
The following byte sequence is repeated for each job from 1 to
"Number of jobs". The byte numbers shift accordingly.
11
Unsigned
Char
0xXX
Number of subsequent bytes. This can be used to
specify a unique name for job n.
11 ... n Char 0xXX
From this position, the name for job n follows in the
specified length.
n + 1 ... n Unsigned
0xXX
Number of subsequent bytes. A description for job n
06814859 - 1/24/2019-00 Page 218 EN
