VISOR
®
Communications manual
Set trigger delay (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Set trigger delay (binary) request string to sensor
Byte no.. Data type Content Meaning
1 - 4 Unsigned Int 0xB Telegram length
5
Unsigned
Char
0x27 Set trigger delay
6
Unsigned
Char
0xX1 Request version
7
Unsigned
Char
0xXX
0: Temporary
1: Permanent
8 - 11 Unsigned Int 0xXX
Trigger delay
in msec (max. 3000 msec)
in encoder steps (max. 65535 steps)
Set trigger delay (binary) response string from sensor
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0x07 Telegram length
5
Unsigned
Char
0x1A Set trigger delay
6 - 7
Unsigned
Short
0xXX Error codes (Page 88)
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Accepted when Ready is low: Yes
Status of Ready signal during
processing:
Low
Supported interfaces:
Telegrams: Availability and supported interfaces
(Page 85)
Page 223 EN 06814859 - 1/24/2019-00
