Data output in BINARY
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Output data (BINARY), dynamically put together based on the user settings in the
software:SensoConfig/Output/Data output.
Basic string construction:
<START> (((<OPTIONAL FIELDS> <PAYLOAD>))) <CHKSUM> <TRAILER>
Output data (BINARY):
<OPTIONAL FIELDS>
Parameter
Description
Length
Binary
[Byte]
Data type
Available
for
Selected
fields
This
checkbox
shows all
selected fields.
The
checkbox for
selected
fields is not
selected fields.
2
ASCII: The output order is from left to
right and from top to bottom, i.e., for each
checkbox that is enabled, a byte is set
beginning with the LSB.
Binary: The output order is from left to
right and from top to bottom, i.e., for each
checkbox that is enabled, a bit is set
beginning with the least significant one.
All types
Telegram
length
Number of
characters,
incl.
2
ASCII: E.g., output string with 10
characters; telegram length: 10 + 2
characters (one byte per whole number
place) = 12
All types
