VISOR
®
Communications manual
Set parameter (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Set parameter (binary) request string to sensor
Byte no. Data type Content Meaning
1 - 4
Unsigned
Int
0xXX
Telegram length = 9 bytes + length of reference
string (n)
5
Unsigned
Char
0x05
0x06
Set parameter permanent
Set parameter temporarily
Permanent change affect all parameters, including
those that were previously only changed
temporarily.
6
Unsigned
Char
0xXX Detector no., XX = 1- n
7
Unsigned
Char
0xXX
Command reference string / Set value *1), see
below !
8 - 9
Unsigned
Short
0xXX Length new reference string / value (n)
10 ... n
Unsigned
Char
0xXX Reference string / value
Set parameter (binary) response string from sensor (may arrive with a delay of up
to 4–5 seconds)
Byte no. Data type Content Meaning
1 - 4
Unsigned
Int
0x08 Telegram length
5
Unsigned
Char
0x05
0x06
Set parameter permanent
Set parameter temporary
Permanent change affect all parameters, including
those that were previously only changed
temporarily.
6 - 7
Unsigned
Short
0xXX Error codes (Page 88)
8
Unsigned
Char
0xXX Parameter type string
Additional information:
06814859 - 1/24/2019-00 Page 208 EN
