VISOR
®
Communications manual
Calibration: Set fiducial (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Calibration: Set fiducial (ASCII) request string to sensor
Byte no. Content Meaning
1 C
Calibration: Set Fiducial2 S
3 F
4 1 Request version
5 X
0: Temporary
1: Permanent
Example: CSF11
Calibration: Set fiducial (ASCII) response string from sensor
Byte no. Content Meaning
1 C
Calibration: Set Fiducial2 S
3 F
4
P
F
P successful (Pass)
F Fail
5 - 7 X Error codes (Page 88)
8 - 15 X X value
16 - 23 X Y value
24 - 31 X Z value
32 - 39 X Rot X value
40 - 47 X Rot Y value
48 - 55 X Rot Z value
56 - 63 X Deviation fiducials, mean
Page 149 EN 06814859 - 1/24/2019-00
