VISOR
®
Communications manual
Status of Ready signal during processing: No change
Supported interfaces:
Telegrams: Availability and
supported interfaces (Page 85)
Parameter
name
Parameter
number
Parameter
value
Length Format Status
Unit (user
unit)
004
0: mm
1: cm
2: m
3: inch
4: au
1 Byte Characters no change
Z Offset 021
(in user unit *
1000)
8 Byte Signed integer no change
Focal length 022 (in mm *1000) 8 Byte Signed integer invalid
Fiducial 1 024
in each case:
0: X value (in
user unit *
1000)
1: Y value (in
user unit *
1000)
2: Z value (in
user unit *
1000)
8 bytes
per value
Signed integer no change
Fiducial 2 025
Fiducial 3 026
Fiducial 4 027
Page 241 EN 06814859 - 1/24/2019-00
