Sensopart Visor - Read Parameter (BINARY)

VISOR
®
Communications manual
Read parameter (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Read parameter (binary) request string to sensor
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0x07 Telegram length
5 Unsigned Char 0x0A Get Parameter
6 Unsigned Char 0xXX Detector no., XX = 1- n
7 Unsigned Char 0xXX
Read reference string / value *1), see
below!
Read parameter (binary) response string from sensor (may arrive with a delay of up
to 4–5 seconds)
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0xXX
Telegram length = 10 bytes + length
of reference string (n)
5 Unsigned Char 0x0A Get Parameter
6 - 7 Unsigned Short 0xXX Error codes (Page 88)
8 Unsigned Char 0xXX Parameter type string
9 - 10 Unsigned Short 0xXX Length of read parameter (n)
11 ... n + n Unsigned Char 0xXX Reference string / value
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Accepted when Ready is low: Yes
Status of Ready signal during processing: No change
Supported interfaces:
Telegrams: Availability and supported
interfaces (Page 85)
