VISOR
®
Communications manual
*1) Byte No. 7: Command: Read reference string / value
Detector Function Command
Length of the following
data
Alignment Pattern matching
Threshold Min
Threshold Max
ResultOffsetPos_X
ResultOffsetPos_Y
ResultOffsetAngle
1
2
31
32
33
4
4
5
5
5
Alignment Contour
comparison
Threshold Min
Threshold Max
ResultOffsetPos_X
ResultOffsetPos_Y
ResultOffsetAngle
1
2
31
32
33
4
4
5
5
5
Alignment Edge detection
Transition probe 1
Transition probe 2
Transition probe 3
Score min probe 1
Score min probe 2
Score min probe 3
101
102
103
104
105
106
4
4
4
4
4
4
Pattern matching
Threshold Min
Threshold Max
ResultOffsetPos_X
ResultOffsetPos_Y
ResultOffsetAngle
1
2
31
32
33
4
4
5
5
5
Contour comparison
Threshold Min
Threshold Max
ResultOffsetPos_X
ResultOffsetPos_Y
ResultOffsetAngle
1
2
31
32
33
4
4
5
5
5
Grayscale
Threshold Min
Threshold Max
GrayMin
GrayMax
GrayInvert
1
2
101
102
103
4
4
4
4
1
06814859 - 1/24/2019-00 Page 212 EN
