Set gain value (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Set gain (binary) request string to sensor
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0x0A Telegram length
5 Unsigned Char 0x1B Set Gain
6 Unsigned Char 0xXX
0: Temporary
1: Permanent
Permanent change affect all parameters,
including those that were previously only
changed temporarily.
7 - 10 Unsigned Int 0xXX Gain value
Set gain (binary) response string from sensor
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0x0B Telegram length
5 Unsigned Char 0x1B Set Gain
6 - 7 Unsigned Short 0xXX Error codes (Page 88)
8 - 11 Unsigned Int 0xXX Current gain value (value *1000)
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Accepted when Ready is low: Yes
Status of Ready signal during processing: No change
Supported interfaces:
Telegrams: Availability and supported
interfaces (Page 85)
06814859 - 1/24/2019-00 Page 206 EN
