Calibration: Point list (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Calibration with point list (ASCII) request string to sensor
Byte no. Content Meaning
1 C
Calibration: Calibrate by Point List2 C
3 L
4 X
0: Temporary
1: Permanent
Example: CCL1
Calibration with point list (ASCII) response string from sensor
Byte no. Content Meaning
1 C
Calibration: Calibrate by Point List2 C
3 L
4
P
F
P successful (Pass)
F Fail
5 - 9 X Current highest point pair index
10 - 17 X
Deviation calibration, RMSE (root mean
square error)
18 - 25 X Deviation calibration, mean
26 - 33 X Deviation calibration, max.
34 - 41 X Deviation calibration, min.
Example: CCLP0001012345678123456781234567812345678
Additional information:
Accepted in run mode: Yes
