VISOR
®
Communications manual
13 - 20 X Image point X
21 - 28 X Image point Y
Example:
CAWP000000010028800000566000 (Reference point 1; Image X = 288; Image
Y = 566)
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Accepted when Ready is low: Yes
Status of Ready signal during processing: No change
Supported interfaces:
Telegrams: Availability and supported
interfaces (Page 85)
End of telegram: Max. 4 bytes (optional)
Page 141 EN 06814859 - 1/24/2019-00
