VISOR
®
Communications manual
Read operating distance (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Read operating distance (binary) request string to sensor
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0x7 Telegram length
5
Unsigned
Char
0x30 Get Focus
6
Unsigned
Char
0xX1 Request version
7
Unsigned
Char
0xXX
Unit
0 - 1/1000 millimeters
4 - steps
Read operating distance (binary) response string from sensor
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0x0B Telegram length
5
Unsigned
Char
0x31 Get Focus
6 - 7
Unsigned
Short
0xXX Error codes (Page 88)
8 - 11 Int 0xXX Current operating distance
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Accepted when Ready is low: Yes
Status of Ready signal during processing: No change
Supported interfaces:
Telegrams: Availability and supported interfaces
(Page 85)
Page 201 EN 06814859 - 1/24/2019-00
